Denotation:
Do not mix between VHDL coding standards for the whole project.
Use VHDL-93.
Everything (all VHDL keywords and all user-defined identifier) shall be in lower case.
All user-defined identifiers shall be meaningful and have words separated by underscores, based on the English language.
The same identifier name as for the actual hardware and as in the data sheet.
For signals and variables that are active low, this shall clearly indicated by their by suffixing n as in “reset_n”.
Named association shall be used preferably to positional association.
For objects that are global, this shall clearly indicate by their suffix “_gc”
Underscores should be used in literals.
Only literals in base 2, 8, 10, 16 shall be used.
Extended digits in base-16 literals should be in lowercase.
Variable width ports shall be constrained using generics.
Positioning:
Declarative regions and blocks shall be indented by four spaces.
Indentation level in sequential statements shall not exceed 4.
Indented regions in sequential statements shall not have more than 60 lines.
The TAB character shall not be used to indent, only use the space character.
Lines should not exceed 120 characters.
Long Lines shall be broken where there are white spaces.
Line continuations shall be indented to line-up with the first token at the same nesting level or by four spaces.
One lines shall separate concurrent statements and their descriptive comment.
Groups of logically related statements and declaration shall be separated by one blank line.
Unless otherwise specified, tokens shall be separated by one space.
No space shall precede a close parenthesis or semi-colon.
No space should surround a single quote or dot.
Each statement shall start on a new line.
Each declaration shall start on a new line.
Elements in interface declarations shall be vertical aligned.
Elements in signal, constant declarations shall be vertical aligned.
Elements in a named association than span more than one line should be vertical aligned.
Buffer and Linkage ports shall not be used.
Guarded blocks and guarded signals should not be used.
Operators shall not be overloaded lightly.
Attributes ‘range and ‘reverse_range shall be used when scanning arrays.
Enumerates shall be used to represent non-arithmetic discrete values.
Use too many parentheses, never let the tool resolve precedence; explicitly declare precedence via parenthesis.
Use relativ path.
Include only libraries which are really use in the design!
For interfacing other modules use only std_logic and std_logic_vector as type.
For arithmetic operations use library ieee.std_logic_signed_bit.all and ieee.std_logi0.06"c_signed.all
Use preferred libraries ieee.std_logic_1164.all, std.text.all and std.logic_textio.all
.
Comments:
Comments shall be immediately followed by the code they describe.
Comments for port and signal declarations shall be in the same line.
Each file should have descriptive comment of the content at the top.
